Productionising ROS when you have no choice
(with Bazel)
Ricardo Delfin
About Me
# INTRO
Facebook - Production Engineer
- Server Provisioning
- Web Monitoring
- Incident Management
Humanoid - Robotics Software Engineer
- System Integration
- Data Collection Devices
- Deployment
Bloomberg - Software Engineer
- Kernel Deployment
- Observability
- Performance Investigation
Wayve - Robotics Software Engineer
- Sensor Integration
- Overall Software Integration
- Monitoring
# BACKGROUND
Why ROS?
- Standard for robotics research
- Quick to setup
- Widespread robot support
- Lots of out-of-the-box hardware support
- Easily extensible
- Composable
Source: https://www.ros.org/
# BACKGROUND
Why not ROS?
- Primary deployment by dpkg
- No obvious boot-time launch
- Colcon
- Tied to specific Ubuntu releases
- Often non-deterministic
- Illusion of repeatability
- rosmsg aren't backwards compatible
- Show-stopping bugs in the shared memory topic interface
- Good lord so many timing bugs
Source: https://jellycat.com/timmy-turtle/
# BACKGROUND
But what if I have to?
- You want to get:
- Clear dependency definitions
- Build isolation (hermetic builds)
- Portability
- Reproducibility
- Cheap, fast builds (caching)
# BACKGROUND
But what if I have to?
- You want to get:
- Clear dependency definitions
- Build isolation (hermetic builds)
- Portability
- Reproducibility
- Cheap, fast builds (caching)
- Bazel!
Source: https://bazel.build/
Examples:
https://github.com/rdelfin/ros2_bazel_examples
# BUILD
Building ROS
-
https://github.com/mvukov/rules_ros2/
- Builds ROS from source
- Fully featured
- Self-contained runtime (few system libs)
- Pinned ROS version
- Independent from Linux distro
Source: https://www.flickr.com/photos/17739115@N00/9900702084
Sample Node Build
package(default_visibility = ["//visibility:public"])
load("@com_github_mvukov_rules_ros2//ros2:cc_defs.bzl", "ros2_cpp_binary")
load("@com_github_mvukov_rules_ros2//ros2:launch.bzl", "ros2_launch")
load("@rules_python//python:defs.bzl", "py_binary")
load("@com_github_mvukov_rules_ros2//third_party:expand_template.bzl", "expand_template")
ros2_cpp_binary(
name = "talker",
srcs = ["talker.cpp"],
deps = [
"@fmt",
"@ros2_rclcpp//:rclcpp",
"//interface:cpp_rdelfin_msgs",
],
)
py_binary(
name = "listener",
srcs = ["listener.py"],
deps = [
"@ros2_rclpy//:rclpy",
"//interface:py_rdelfin_msgs",
],
)
ros2_launch(
name = "launch_nodes",
launch_file = "nodes.launch.py",
nodes = [
":talker",
":listener",
],
)# BUILD
from launch import LaunchDescription
from launch.actions import (
RegisterEventHandler,
Shutdown,
)
from launch.event_handlers import OnProcessExit
from launch_ros.actions import Node
def generate_launch_description():
return LaunchDescription([
Node(
name="talker_node",
executable="nodes/talker",
),
Node(
name="listener_node",
executable="nodes/listener",
),
])# BUILD
# DOCKER
Deployment - Container
- Deploy ROS nodes as container
- Quick to setup
- Isolated environment
- Widely supported
- Can be setup at boot
- https://github.com/bazel-contrib/rules_oci
- https://github.com/bazel-contrib/rules_distroless
Source: https://www.flickr.com/photos/14445655@N04/1494590209
Docker: Code
package(default_visibility = ["//visibility:public"])
load("@rules_oci//oci:defs.bzl", "oci_image", "oci_load")
load("@rules_pkg//pkg:tar.bzl", "pkg_tar")
load("@rules_pkg//pkg:mappings.bzl", "pkg_files", "strip_prefix", "pkg_attributes")
PY_RUNTIME_BINARIES = [
"@python_3_10_x86_64-unknown-linux-gnu//:bin/2to3",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/2to3-3.10",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/idle3",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/idle3.10",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/pip",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/pip3",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/pip3.10",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/pydoc3",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/pydoc3.10",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/python",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/python3",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/python3-config",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/python3.10",
"@python_3_10_x86_64-unknown-linux-gnu//:bin/python3.10-config",
]
# Separate bin files for executable permissions
filegroup(
name = "python_bins",
srcs = PY_RUNTIME_BINARIES,
)
# Executable Python binaries with 0755 permissions
pkg_files(
name = "python_runtime_bins",
srcs = [":python_bins"],
prefix = "/usr/local/python",
strip_prefix = strip_prefix.from_pkg(),
attributes = pkg_attributes(
mode = "0755",
),
)
# Non-executable Python runtime files (libraries, headers, etc.) with 0644 permissions
pkg_files(
name = "python_runtime_libs",
srcs = ["@python_3_10_x86_64-unknown-linux-gnu//:files"],
prefix = "/usr/local/python",
strip_prefix = strip_prefix.from_pkg(),
excludes = PY_RUNTIME_BINARIES,
)
pkg_tar(
name = "python_runtime_tar",
srcs = [
":python_runtime_libs",
":python_runtime_bins",
],
symlinks = {
"/usr/bin/python3": "/usr/local/python/bin/python3",
"/usr/bin/python3.10": "/usr/local/python/bin/python3.10",
},
)
pkg_tar(
name = "nodes_runfiles_tar",
srcs = [
"//nodes:talker",
"//nodes:listener",
"//nodes:launch_nodes",
],
package_dir = "/usr/lib/ros_src",
include_runfiles = True,
)
oci_image(
name = "app_image",
base = "@ros_base",
workdir = "/usr/lib/ros_src/launch_nodes.runfiles/_main",
cmd = "command.txt",
tars = [
":python_runtime_tar",
":nodes_runfiles_tar",
],
)
oci_load(
name = "load_app",
image = ":app_image",
repo_tags = ["app:latest"],
)
# DOCKER
# DOCKER
# PACKAGES
Deployment - Packages
- DPKG/RPM Solution
- Installs on the base system
- Requires a solution for runfiles
- Requires service deployment (e.g. systemd)
- Easily deployable!
- https://github.com/bazelbuild/rules_pkg
Source: https://www.flickr.com/photos/51526368@N03/5116363810
Deployment - Packages
load("@rules_pkg//pkg:deb.bzl", "pkg_deb")
load("@rules_pkg//pkg:mappings.bzl", "pkg_files")
load("@rules_pkg//pkg:tar.bzl", "pkg_tar")
pkg_files(
name = "ros_nodes_service",
srcs = ["ros_nodes.service"],
prefix = "usr/lib/systemd/system",
)
pkg_tar(
name = "launch_nodes_tar",
srcs = [":ros_nodes_service"],
symlinks = {
"/usr/bin/launch_nodes": "/usr/lib/ros_src/launch_nodes",
},
deps = ["//docker:nodes_runfiles_tar"],
)
pkg_deb(
name = "launch-nodes-deb",
architecture = select({
"@platforms//cpu:arm64": "arm64",
"@platforms//cpu:x86_64": "amd64",
}),
data = ":launch_nodes_tar",
description = "Launch Nodes",
maintainer = "Ricardo Delfin",
package = "launch-nodes",
postinst = "postinst.launch_nodes",
prerm = "prerm.launch_nodes",
version = "0.1.0",
)# PACKAGES
[Unit]
Description=ROS Nodes
[Service]
ExecStart=/usr/bin/launch_nodes
WorkingDirectory=/usr/lib/ros_src/launch_nodes.runfiles/_main
Environment=HOME=/root
[Install]
WantedBy=multi-user.target
# IMAGES
Deployment - Images
- Sysroot and image-based deployment
- Converges system and build environment
- Avoids dynamic linker issues
- Avoids differences in different environments
- Lets you setup remote caching
- Many tools for this:
- yocto
- mmdebstrap
- rules_distroless
- ...
Source: https://www.flickr.com/photos/75243940@N00/859194667
Deployment - Images
load("@rules_pkg//pkg:tar.bzl", "pkg_tar")
pkg_tar(
name = "flat_rootfs",
deps = [
"//distroless:sh",
"//distroless:passwd",
"//distroless:group",
"@noble//:noble",
"//docker:python_runtime_tar",
"//docker:nodes_runfiles_tar",
],
)# PACKAGES
# OTA
OTA Updates
- Make sure you have:
- Deployment capabilities
- Monitoring and health-checking
- Remote access (if security allows)
-
https://mender.io/
- Extensible
- Wide set of features
- Solid fleet management
Source: https://github.com/mendersoftware
